概述
PRECiV测量和成像平台
专为检测和测量任务而设计
不折不扣 — PRECiV软件的工作方式与大多数流行的工业和材料科学应用的工作方式相同,还可为某些主要任务和应用提供专用功能,例如:
- 半导体:使用红外成像功能探测缺陷,使用电动载物台进行晶圆导航,工业显微镜控制,以及简单的三维测量
- 电子设备:EFI可为厚部件进行清晰成像,为记录和报告而进行的目视检测,扩展的二维测量
- 金属:使用二维测量、材料解决方案、全景成像和EFI功能,检测样品中的宏观结构断裂,确定参数,并评估异常情况和失效机制
- 航空航天:验证单个部件的质量,使用自动化功能重建大截面,并使用图像分析评估故障
- 汽车:部件质量控制、焊件测量和控制,以及对发动机部件、变速器和制动系统进行检测
制造产品的测量和成像平台尽在您的掌控中
在生产、质量控制和检测操作中轻松进行可重复的二维测量和高级图像分析。
- 通过可重复性工作流程获得符合最新工业标准的结果
- 使用人工智能(AI)技术轻松分析复杂图像
- 创建可导出到您公司网络上的专业报告
- 凭借强大的数据共享和安全功能,实现快速、高效的工作流程
易于使用的工业显微镜成像、测量和分析工具
直观简便、协作性强
用户界面易于使用,经过简单的培训就可使用软件的强大工具。通过标记清晰的大按钮,可以轻松访问软件的各项功能,如观察、采集、测量和分析,以快速获取高质量的图像,并在实时和静态图像上进行准确的二维测量和图像分析。
只需简单培训即可使用该软件
对于刚入行的用户来说,高级设置处于隐藏状态,保持了界面的简洁性。经验丰富的用户可以通过“更多”按钮,访问所有的设置和功能。您可以自定义主屏幕,以快速访问经常使用的功能。
打开软件后,实时图像将自动启动,因此您可以直接开始工作。
模块化和多用途的工业显微镜图像和测量软件
扩展您的工业显微镜的功能
该软件是为您的工业显微镜实验室提供的一种综合性成像和测量解决方案。PRECiV软件可以控制Evident常规工业显微镜、显微镜编码功能、电动物镜转换器和数码相机。此外,该软件还支持精选的第三方电动设备,包括电动载物台、载物台控制器和聚焦驱动器。
电动化助力您自动完成工作流程
使用该软件控制手动和半自动工业显微镜以及电动X、Y、Z设备。有经验的用户使用专门的用户界面可以有效地控制电动载物台和聚焦驱动器,以获取延时图像、视频或三维图像。
使用宏可自动执行重复性任务
PRECiV软件支持宏,自动执行重复性任务并简化工作流程,包括交互式测量(链式测量)。可以记录和重放简单的宏,同时还可以记录一组扩展的命令,包括使用神经网络进行图像处理和创建批处理。
可靠准确的结果
该软件带有专用的二维测量功能,如自动边缘检测和辅助线,以及基于人工智能(AI)的图像分析、材料解决方案等。
安装简便
该软件可无缝集成您的工业显微镜、奥林巴斯相机和配件。在安装过程中,还会安装所有必要的驱动程序,从而可使您轻松适应您所使用的产品。
选择您的 | ||||
工业显微镜机架 | 相机 | 配件 | 软件 | |
传统 | 体视 | |||
BX41M-LED
BXFM BX51 BX51M BX53M BX3M-CB BX3M-CBFM GX41 GX51 GX53 GX71 MX63 MX63L MX51 |
SZ61
SZX7 SZX9 SZX10 SZX12 SZX16 | LC30 LC35 DP22 DP23 DP23M DP27 DP28 DP73 DP73 WDR DP74 SC30 SC50 SC100 SC180 UC90 |
U-MIXR
来自Chuoseiki、Ludl、Märzhäuser和Prior等制造商的第三方载物台、控制器、聚焦驱动器等 |
PRECiV Capture
PRECiV Core PRECiV PRO PRECiV Desktop |
有许多硬件和相机的组合可供选择
*1 由HAMAMATSU PHOTONICS K.K.制造。
*2 由SCHOTT开发
PRECiV Capture
PRECiV™ CaptureEntry-Level Package with Core FeaturesPRECiV™ Capture is our entry-level package for customers who want to acquire digital images and make basic 2D measurements, transforming their existing microscopes into digital workstations for applications like incoming goods inspection. |
Designed for Conventional MicroscopyPRECiV Capture is used with our manual and semi-motorized microscope systems and microscope cameras as well as accessories that enable a range of imaging conditions, including brightfield, darkfield, polarization, and anti-halation. When you install PRECiV Capture all the necessary drivers are also installed, making it easy to change which products you’re using. Supported Microscope Frames
Supported Cameras
|
Reveal More with Infrared (IR)IR imaging is a fundamental tool for quality control and in R&D laboratories. IR mode enables nondestructive inspection through silicon layers of packaged products during the back-end stage of fabrication. PRECiV Capture has a dedicated shading correction mode for the monochrome cameras used in IR imaging. |
Real-Time Image AcquisitionAll PRECiV packages come with digital live processing technology that enable you to, for example, zoom in on a live image to proof details or make interactive measurements. Acquiring high-quality images is easy as the software’s automatic exposure control, live histogram display, and over-exposure indicator helps ensure that the entire dynamic range of the camera is used while minimizing blooming or glare artifacts. The focus indicator enables you to select a region of interest and bring it into focus. The digital zoom—operated with the mouse wheel—enables you to quickly check the live image window to be sure the camera has captured the desired details—all before you actually acquire and save the image. As a result, images are produced with maximum fidelity and reproducibility, independent of the user. |
Live Image FunctionsPRECiV Capture software’s live image functions, like live overlay and live zoom, enable you to interact with the automatically calibrated live image and perform various annotations. |
Powerful Imaging ToolsDuring live observation or post-acquisition image analysis, PRECiV Capture offers several image-enhancing tools that advance your inspection capabilities and increase your probability of detection. PRECV Capture supports:
Robust color rendering and resolution provide the high-quality images required for industrial applications. PRECiV Capture also has convenient tools that enable you to optimize the live image, including live high dynamic range (HDR), anti-glare, a digital reticle, and a focus aid. | |
Enhanced ContrastHigh dynamic range (HDR) imaging improves image contrast in difficult conditions (very bright areas together with very dark areas in the same image). All cameras supported by PRECiV Capture can be used in this mode, and dedicated cameras have an available live mode. |
Basic MeasurementsPRECiV Capture software enables precise, repetitive two-dimensional interactive measurements on a live or recorded image through a combination of a simple user interface and powerful functions. Supported measurements include distance, angles, rectangles, circles, ellipses, polygons, circle-to-circle distance, angle ruler, and line ruler. Measurement results can be easily compiled in a workbook. |
PRECiV Core
PRECiV™ CoreFocused on Image QualityPRECiV™ Core is ideal for customers in QA labs and inspection rooms with a strong focus on images. PRECiV Core balances cost and features, adding extended focus images and measurement export capabilities for an excellent value. |
Designed for Conventional MicroscopyPRECiV Core works with our manual and semi-motorized microscope systems, microscope cameras, and accessories that enable a range of imaging conditions, including brightfield, darkfield, polarization, and anti-halation. When you install PRECiV Core and any optional modules, all the necessary drivers are also installed, making it easy to change which products you’re using. Supported Microscope FramesPRECiV Core supports:
Supported Cameras
Supported Motorized Stages
*Virtual COM port (driver needs to be installed, supplied on the PRECiV setup disk) Customized Software Solutions for X, Y, Z Motorized StagesSpecially developed customized software solutions expand the X, Y, Z motorization.
|
Real-Time Image AcquisitionAcquiring high-quality images is easy as the software’s automatic exposure control, live histogram display, and the over-exposure indicator helps ensure that the entire dynamic range of the camera is used while minimizing blooming or glare artifacts. The focus indicator enables you to select a region of interest and bring it into focus. The digital zoom—operated with the mouse wheel—enables you to quickly check the live image window to be sure the camera has captured the desired details—all before you actually acquire and save the image. As a result, images are produced with maximum fidelity and reproducibility, independent of the user. |
Powerful Imaging ToolsDuring live observation or post-acquisition image analysis, PRECiV Core offers several image-enhancing tools that advance your inspection capabilities and increase your probability of detection. PRECiV Core supports:
Robust color rendering and resolution provide the high-quality images required for industrial applications. PRECiV Core also has convenient tools that enable you to optimize the live image, including live high dynamic range (HDR), anti-glare, a digital reticle, and a focus aid. Enhanced ContrastHigh dynamic range (HDR) imaging improves image contrast in difficult conditions (very bright areas together with very dark areas in the same image). All cameras supported by PRECiV Core can be used in this mode, and dedicated cameras have an available live mode. MIX ObservationPRECiV Core supports MIX observation. This technique combines directional darkfield illumination, which uses a circular LED to illuminate one or more quadrants at a given time, and brightfield illumination, fluorescence, or polarization, enabling users to highlight defects and differentiate raised surfaces from depressions that are normally difficult to see with conventional microscopes. MIX observation helps reduce a sample’s halation and is useful for visualizing a sample’s surface texture.
|
Keep Everything in Focus with Manual and Instant EFI Modes
When analyzing thick samples, PRECiV Core features instant extended focal imaging (instant EFI) technology that enables you to obtain fully in-focus images by serially acquiring multiple images at different focal planes with manual devices. Starting with a simple mouse click, simply focus through the sharpness levels of your sample from top to bottom (or vice versa), and the program takes a series of snapshots and calculates one sharp image. The result can be viewed in real time during the acquisition process. |
Basic MeasurementsPRECiV Core software enables precise, repetitive two-dimensional interactive measurements on a live or recorded image through a combination of a simple user interface and powerful functions. Supported measurements include distance, angles, rectangles, circles, ellipses, polygons, circle-to-circle distance, angle ruler, and line ruler,. Measurement results can be easily compiled in a workbook and exported to Microsoft Excel. |
Automate Repetitive Tasks with MacrosThe PRECiV macro manager enables you to automate repetitive tasks and simplify workflows, including interactive measurements (chain measurement). Simple macros can be recorded and replayed, while an extended set of commands can also be recorded, including image processing with a neural network and create batch processing. |
Analyze Complex Images Using AI TechnologySince image quality and contrast varies with the sample, image segmentation using classical thresholding methods lacks reproducibility and repeatability. PRECiV software with TruAI technology provides image analysis beyond classical algorithms. You can apply a trained neural network to your samples for higher reproducibility and more robust analysis. Choose between semantic or instance segmentation methods for improved neural network training, enabling you to tackle difficult applications in just one step. |
PRECiV Core Optional Modules |
3D Acquisition—Coded and motorized Z-control with height mapping capabilities. Motorization—Control industrial and material science manual and semi-automated microscopes and motorized devices. Customized Software Solutions—Software solutions supporting X, Y, Z motorized stages (Macro to Micro, Navigate on Wafer, Measuring with stage). Neural Network Training—Train neural networks using semantic (for well separated or when object separation is irrelevant) or instance (for objects that touch, like grains) segmentation methods. 3D analysis applications—3D line profile measurements, advanced 3D measurements, and surface roughness analysis of 3D images. Count and Measure—Detecting objects and measuring size distribution are among the most important applications in digital imaging. The PRECiV Count and Measure solution uses advanced threshold methods to reliably separate objects, such as particles and scratches, from the background. Grain Sizing—Steel manufacturers use this solution for measuring and controlling grain size after cross-sectioning, polishing, or etching steel samples. Grain Sizing Intercept is based on overlaying test lines and counting the number of intercepts with grain boundaries, while Grain Sizing Planimetric reconstructs boundaries for each grain and conducts grain sizing with the area percentage of the second phase. Non-Metallic Inclusions—Steel manufacturers use this solution for measuring and controlling the shape and size of nonmetallic inclusions (oxide, alumina, sulfide, or silicate) in steel. Cast Iron—Casting manufacturers who need to measure and control the graphite nodularity and check the mechanical characteristics of their cast products use this solution. Layer Thickness—One or multiple layers of a cross-sectioned sample can be measured using the Layer Thickness solution. The shapes are defined, and the layers automatically measured. Porosity—This solution enables pores to be measured either for area fraction or the number of surface pores using regions of interest (ROIs) (circular, triangular, rectangular, and polygonal) and thresholds. Particle Distribution—This solution is used to create particle size distribution histograms and tables from multiple images or image series. Coating Thickness—This solution enables the measurement of coating thickness from top-view images using the Calotest method. Phase Analysis—This feature offers an integrated solution to perform phase analysis on a selection of various regions of interest (ROIs) including triangles, circles, rectangles, and polygons. Dendrite Arm Spacing—This solution is used to manually or automatically determine the mean dendrite arm spacing in cast aluminum. Chart Comparison on Selected Standards for Grain Sizing, Graphite Sizing, Non-Metallic Inclusion, and Hardened Metals—A live or still image can be overlaid onto standard charts for comparison. Function preview is available. |
PRECiV Pro
PRECiV™ ProRobust Measurement and ReportingPRECiV™ Pro has the complete set of features and functions, making it the most powerful and versatile version of the software. The Pro version has the tools required for customers in QA/QC, failure analysis, and anyone who needs to produce analytical reports and measurements to validate a sample or production lot. |
Designed for Conventional MicroscopyPRECiV Pro works with our manual and semi-motorized microscope systems, microscope cameras, and accessories that enable a range of imaging conditions, including brightfield, darkfield, polarization, and anti-halation. When you install PRECiV Pro and any optional modules, all the necessary drivers are also installed, making it easy to change which products you’re using. Supported Microscope FramesPRECiV Pro supports:
Supported Cameras
Supported Motorized Stages
*Virtual COM port (driver needs to be installed, supplied on the PRECiV setup disk) Customized Software Solutions for X, Y, Z Motorized Stages
|
Real-Time Image AcquisitionAll PRECiV packages come with digital live processing technology that enable you to, for example, zoom in on a live image to proof details or make interactive measurements. Acquiring high-quality images is easy as the software’s automatic exposure control, live histogram display, and the over-exposure indicator helps ensure that the entire dynamic range of the camera is used while minimizing blooming or glare artifacts. The focus indicator enables you to select a region of interest and bring it into focus. The digital zoom—operated with the mouse wheel—enables you to quickly check the live image window to be sure the camera has captured the desired details—all before you actually acquire and save the image. As a result, images are produced with maximum fidelity and reproducibility, independent of the user. |
Movie Recording and Time-Lapse ImagingYou can easily record movies or use the time-lapse acquisition mode to acquire and process time-lapse series. |
Powerful Imaging ToolsDuring live observation or post-acquisition image analysis, PRECiV Pro offers several image-enhancing tools that advance your inspection capabilities and increase your probability of detection. PRECiV Pro supports:
Robust color rendering and resolution provide the high-quality images required for industrial applications. PRECiV Pro also has convenient tools that enable you to optimize the live image, including live high dynamic range (HDR), anti-glare, a digital reticle, and a focus aid. Enhanced ContrastHigh dynamic range (HDR) imaging improves image contrast in difficult conditions (very bright areas together with very dark areas in the same image). All cameras supported by PRECiV Pro can be used in this mode, and dedicated cameras have an available live mode. MIX ObservationPRECiV Pro supports MIX observation. This technique combines directional darkfield illumination, which uses a circular LED to illuminate one or more quadrants at a given time, and brightfield illumination, fluorescence, or polarization, enabling users to highlight defects and differentiate raised surfaces from depressions that are normally difficult to see with conventional microscopes. MIX observation helps reduce a sample’s halation and is useful for visualizing a sample’s surface texture.
|
Acquire Combined Panorama and EFI ImagesThe extended focal imaging (EFI) function enables you to obtain fully in-focus images by serially acquiring multiple images at different focal planes with manual and motorized devices. In manual mode, the panorama function enables you to acquire images larger than the microscope’s field of view by moving the stage across the sample manually or using an automated stage. Using PRECiV Pro software, you can now combine the instant EFI and panorama functions—even for manual microscope stages—while keeping both hands on the microscope. A colored frame indicator shows the quality of each image being stitched together, while a split screen shows the live image and stitched image side by side. With motorized devices, the acquisition of such combined panorama and EFI images runs completely automatically*. *Requires the optional modules Motorization or 3D Acquisition
|
Advanced Interactive MeasurementsPRECiV Pro enables precise, repetitive two-dimensional measurements on a live or recorded image through a combination of a simple user interface and powerful functions like auto edge detection, which makes it easy to reliably measure the distance between points. Other helpful measurement features include:
Measurement results can be compiled in a workbook and easily exported to Excel. |
Automate Repetitive Tasks with MacrosThe PRECiV macro manager enables you to automate repetitive tasks and simplify workflows, including interactive measurements (chain measurement). Simple macros can be recorded and replayed, while an extended set of commands can also be recorded, including image processing with a neural network and create batch processing. |
Analyze Complex Images Using AI TechnologySince image quality and contrast varies with the sample, image segmentation using classical thresholding methods lacks reproducibility and repeatability. PRECiV software with TruAI technology provides image analysis beyond classical algorithms. You can apply a trained neural network to your samples for higher reproducibility and more robust analysis. Choose between semantic or instance segmentation methods for improved neural network training, enabling you to tackle difficult applications in just one step. |
Efficient Report CreationCreating a report often takes longer than capturing the image and taking the measurements. PRECiV Pro provides intuitive report creation to repeatedly produce smart and sophisticated reports based on predefined and customized templates. Editing is simple, and reports can be exported to Microsoft Word, Excel, or PowerPoint. | Professional report that summarizes particle count data, including image details using digital zooming |
PRECiV Pro Optional Modules |
3D Acquisition—Coded and motorized Z-control with height mapping capabilities. Motorization—Control industrial and material science manual and semi-automated microscopes and motorized devices. Customized Software Solutions—Software solutions supporting X, Y, Z motorized stages (Macro to Micro, Navigate on Wafer, Measuring with stage). Neural Network Training—Train neural networks using semantic (for well separated or when object separation is irrelevant) or instance (for objects that touch, like grains) segmentation methods. 3D analysis applications—3D line profile measurements, advanced 3D measurements, and surface roughness analysis of 3D images. Count and Measure—Detecting objects and measuring size distribution are among the most important applications in digital imaging. The PRECiV Count and Measure solution uses advanced threshold methods to reliably separate objects, such as particles and scratches, from the background. Grain Sizing—Steel manufacturers use this solution for measuring and controlling grain size after cross-sectioning, polishing, or etching steel samples. Grain Sizing Intercept is based on overlaying test lines and counting the number of intercepts with grain boundaries, while Grain Sizing Planimetric reconstructs boundaries for each grain and conducts grain sizing with the area percentage of the second phase. Non-Metallic Inclusions—Steel manufacturers use this solution for measuring and controlling the shape and size of nonmetallic inclusions (oxide, alumina, sulfide, or silicate) in steel. Cast Iron—Casting manufacturers who need to measure and control the graphite nodularity and check the mechanical characteristics of their cast products use this solution. Layer Thickness—One or multiple layers of a cross-sectioned sample can be measured using the Layer Thickness solution. The shapes are defined, and the layers automatically measured. Porosity—This solution enables pores to be measured either for area fraction or the number of surface pores using regions of interest (ROIs) (circular, triangular, rectangular, and polygonal) and thresholds. Particle Distribution—This solution is used to create particle size distribution histograms and tables from multiple images or image series. Coating Thickness—This solution enables the measurement of coating thickness from top-view images using the Calotest method. Phase Analysis—This feature offers an integrated solution to perform phase analysis on a selection of various regions of interest (ROIs) including triangles, circles, rectangles, and polygons. Dendrite Arm Spacing—This solution is used to manually or automatically determine the mean dendrite arm spacing in cast aluminum. Chart Comparison on Selected Standards for Grain Sizing, Graphite Sizing, Non-Metallic Inclusion, and Hardened Metals—A live or still image can be overlaid onto standard charts for comparison. Function preview is available. |
PRECiV DSX
PRECiV™ DSX for Digital MicroscopesPRECiV™ DSX is used to control our DSX1000 series digital microscopes and their accessories. It includes additional features for imaging and 2D/3D measurements. |
ModularPRECiV DSX supports all DSX1000 models and associated accessories. Supported HardwarePRECiV DSX supports both the tilting frame (DSX10-TF) and upright frame (DSX10-UF) versions, the universal and standard zoom heads, the DSX console, and manual, motorized, and rotatable motorized stages.
|
Advanced Interactive MeasurementsPRECiV DSX enables precise, repetitive two-dimensional measurements on a live or recorded image through a combination of a simple user interface and powerful functions like auto edge detection, which makes it easy to reliably measure the distance between points. Other helpful measurement features include:
|
Simple and Advanced 3D measurementsSimple 3D measurements (line profile) are available in PRECiV DSX on all images with height information. For advanced measurements (surface roughness, volume measurement), PRECiV DSX can export images directly to the 3D Analysis Application for further processing and analysis.
|
Acquire Combined Panorama and EFI ImagesThe extended focal imaging (EFI) function enables you to obtain fully in-focus images by serially acquiring multiple images at different focal planes with manual and motorized devices. The panorama function enables you to acquire images larger than the microscope’s field of view. With PRECiV DSX you can calculate extended focal imaging (EFI) and panorama images offline based on previously acquired images. |
Analyze Complex Images Using AI TechnologySince image quality and contrast varies with the sample, image segmentation using classical thresholding methods lacks reproducibility and repeatability. PRECiV software with TruAI™ technology provides image analysis beyond classical algorithms. You can apply a trained neural network to your samples for higher reproducibility and more robust analysis. Choose between semantic or instance segmentation methods for improved neural network training, enabling you to tackle difficult applications in just one step. |
PRECiV DSX Optional Modules |
Neural Network Training—Train neural networks using semantic (for well separated or when object separation is irrelevant) or instance (for objects that touch, like grains) segmentation methods. 3D analysis applications—3D line profile measurements, advanced 3D measurements, and surface roughness analysis of 3D images. Count and Measure—Detecting objects and measuring size distribution are among the most important applications in digital imaging. The PRECiV Count and Measure solution uses advanced threshold methods to reliably separate objects, such as particles and scratches, from the background. Grain Sizing—Steel manufacturers use this solution for measuring and controlling grain size after cross-sectioning, polishing, or etching steel samples. Grain Sizing Intercept is based on overlaying test lines and counting the number of intercepts with grain boundaries, while Grain Sizing Planimetric reconstructs boundaries for each grain and conducts grain sizing with the area percentage of the second phase. Non-Metallic Inclusions—Steel manufacturers use this solution for measuring and controlling the shape and size of nonmetallic inclusions (oxide, alumina, sulfide, or silicate) in steel. Cast Iron—Casting manufacturers who need to measure and control the graphite nodularity and check the mechanical characteristics of their cast products use this solution. Layer Thickness—One or multiple layers of a cross-sectioned sample can be measured using the Layer Thickness solution. The shapes are defined, and the layers automatically measured. Porosity—This solution enables pores to be measured either for area fraction or the number of surface pores using regions of interest (ROIs) (circular, triangular, rectangular, and polygonal) and thresholds. Particle Distribution—This solution is used to create particle size distribution histograms and tables from multiple images or image series. Coating Thickness—This solution enables the measurement of coating thickness from top-view images using the Calotest method. Phase Analysis—This feature offers an integrated solution to perform phase analysis on a selection of various regions of interest (ROIs) including triangles, circles, rectangles, and polygons. Dendrite Arm Spacing—This solution is used to manually or automatically determine the mean dendrite arm spacing in cast aluminum. Chart Comparison on Selected Standards for Grain Sizing, Graphite Sizing, Non-Metallic Inclusion, and Hardened Metals—A live or still image can be overlaid onto standard charts for comparison. Function preview is available. |
PRECiV Desktop
PRECiV™ DesktopRobust Measurement and ReportingPRECiV™ Desktop software is made for customers who want to post-process their data independent from the microscope with all the available measurement and analysis capabilities, but without the camera and image capture controls. |
Image Processing (Matrix Filters and Color and Contrast Adjustments)If you need to process your images, PRECiV Desktop offers many tools such as edge detection filters, smoothing filters, and sharpening filters as well as intensity and contrast adjustments, shading correction and background subtraction, dynamic contrast enhancement, and morphological filters. |
Advanced Interactive MeasurementsPRECiV Desktop enables precise, repetitive two-dimensional measurements on recorded images through a combination of a simple user interface and powerful functions like auto edge detection, which makes it easy to reliably measure the distance between points. Other helpful measurement features include:
Measurement results can be compiled in a workbook and easily exported to Excel. |
Automate Repetitive Tasks with MacrosThe PRECiV macro manager enables you to automate repetitive tasks and simplify workflows, including interactive measurements (chain measurement). Simple macros can be recorded and replayed, while an extended set of commands can also be recorded, including image processing with a neural network and create batch processing. |
3D Line Profile Measurements and Simple 3D MeasurementsPRECiV Desktop supports 3D line profile measurements, advanced 3D measurements, and surface roughness analysis of 3D images acquired with the DSX1000 using the 3D Analysis Application. The image is automatically transferred from PRECiV Desktop to the 3D Analysis Application
|
Analyze Complex Images Using AI TechnologySince image quality and contrast varies with the sample, image segmentation using classical thresholding methods lacks reproducibility and repeatability. PRECiV software with TruAI™ technology provides image analysis beyond classical algorithms. You can apply a trained neural network to your samples for higher reproducibility and more robust analysis. Choose between semantic or instance segmentation methods for improved neural network training, enabling you to tackle difficult applications in just one step. |
Professional report that summarizes particle count data, including image details using digital zooming | Efficient Report CreationCreating a report often takes longer than capturing the image and taking the measurements. PRECiV Desktop provides intuitive report creation to repeatedly produce smart and sophisticated reports based on predefined and customized templates. Editing is simple, and reports can be exported to Microsoft Word, Excel, or PowerPoint. |
PRECiV Desktop Optional Modules |
Neural Network Training—Train neural networks using semantic (for well separated or when object separation is irrelevant) or instance (for objects that touch, like grains) segmentation methods. 3D analysis applications—3D line profile measurements, advanced 3D measurements, and surface roughness analysis of 3D images. Count and Measure—Detecting objects and measuring size distribution are among the most important applications in digital imaging. The PRECiV Count and Measure solution uses advanced threshold methods to reliably separate objects, such as particles and scratches, from the background. Grain Sizing—Steel manufacturers use this solution for measuring and controlling grain size after cross-sectioning, polishing, or etching steel samples. Grain Sizing Intercept is based on overlaying test lines and counting the number of intercepts with grain boundaries, while Grain Sizing Planimetric reconstructs boundaries for each grain and conducts grain sizing with the area percentage of the second phase. Count and Measure—Detecting objects and measuring size distribution are among the most important applications in digital imaging. The PRECiV Count and Measure solution uses advanced threshold methods to reliably separate objects, such as particles and scratches, from the background. Grain Sizing—Steel manufacturers use this solution for measuring and controlling grain size after cross-sectioning, polishing, or etching steel samples. Grain Sizing Intercept is based on overlaying test lines and counting the number of intercepts with grain boundaries, while Grain Sizing Planimetric reconstructs boundaries for each grain and conducts grain sizing with the area percentage of the second phase. Non-Metallic Inclusions—Steel manufacturers use this solution for measuring and controlling the shape and size of nonmetallic inclusions (oxide, alumina, sulfide, or silicate) in steel. Cast Iron—Casting manufacturers who need to measure and control the graphite nodularity and check the mechanical characteristics of their cast products use this solution. Layer Thickness—One or multiple layers of a cross-sectioned sample can be measured using the Layer Thickness solution. The shapes are defined, and the layers automatically measured. Porosity—This solution enables pores to be measured either for area fraction or the number of surface pores using regions of interest (ROIs) (circular, triangular, rectangular, and polygonal) and thresholds. Particle Distribution—This solution is used to create particle size distribution histograms and tables from multiple images or image series. Coating Thickness—This solution enables the measurement of coating thickness from top-view images using the Calotest method. Phase Analysis—This feature offers an integrated solution to perform phase analysis on a selection of various regions of interest (ROIs) including triangles, circles, rectangles, and polygons. Dendrite Arm Spacing—This solution is used to manually or automatically determine the mean dendrite arm spacing in cast aluminum. Chart Comparison on Selected Standards for Grain Sizing, Graphite Sizing, Non-Metallic Inclusion, and Hardened Metals—A live or still image can be overlaid onto standard charts for comparison. Function preview is available. |
Specifications
PRECiV™ Version 2.1 Specifications• : Standard Feature; ◦ : Optional Feature; — Not available |
Capture | Core | Pro | DSX | Desktop | |
Image Acquisition | |||||
---|---|---|---|---|---|
Basic image acquisition from Evident cameras, including auto calibration | • | • | • | — | — |
Extended image acquisition, including HDR, Live HDR (with the DP74 and DP75) and position navigator | • | • | • | — | — |
Halation removal using the MIX slider (microscope) or LED ring light (stereo microscope) | — | • | • | — | — |
Best Image Function (all modes, shadow contrast, BF, OBQ, DF, MIX, PO, DIC) | — | — | — | • | — |
Movie Recording | — | ◦ | • | • | — |
Time-Lapse Acquisition | — | ◦ | • | • | — |
Extended Focal Image (EFI) using manual or instant mode | — | • | • | • | — |
Large-size image acquisition (panorama) using manual or instant mode | — | ◦ | • | • | — |
Combined EFI and panorama using manual mode | — | ◦ | • | • | — |
Automatic EFI using motorized devices, including quick scan mode | — | ◦ | ◦ | • | — |
Automatic Panorama using motorized devices | — | ◦ | ◦ | • | — |
Sample navigation and position list management using motorized devices | — | ◦ | ◦ | • | — |
Combination of automatic EFI and panorama using motorized devices | — | ◦ | ◦ | • | — |
Image and customization tools | |||||
User interface with functions grouped by purpose | • | • | • | • | • |
Overlay information layer (scale bar, cross hair, digital reticle) | • | • | • | • | • |
On-screen magnification | • | • | • | • | — |
Macro Manager | — | • | • | • | • |
Static annotations | • | • | • | • | • |
Live zoom | • | • | • | • | — |
Measurements / Image Analysis | |||||
Basic interactive measurements (arbitrary line, polyline, 3-point circle, rectangle, rotated rectangle, 3-point angle, 4-point angle, perpendicular line, parallel line distance, polygon area, XY distance, distance between two crosslines, circle-to-circle distance, linear ruler, point coordinates) | • | • | • | • | • |
3D Line profile measurement and simple 3D measurements | — | ◦ | ◦ | • | • |
3D analysis applications like 3D line profile measurements, advanced 3D measurements, and surface roughness analysis of 3D images | — | ◦ | ◦ | ◦ | ◦ |
2D Line profile measurements | — | ◦ | • | • | • |
Advanced interactive measurement, including auto-edge detection and auxiliary lines (horizontal line, vertical line, angle ruler, 2-point circle, rotated ellipse, closed polygon, magic wand, interpolated polygon, multiple perpendicular lines, asymmetry lines, throat thickness) | — | ◦ | • | • | • |
Neural Network Labelling | — | • | • | • | • |
Offline EFI, Offline Panorama | — | ◦ | ◦ | • | • |
Image enhancement filters (edge detection filters, smoothing filters, and sharpening filters), intensity and contrast adjustment, shading correction and background subtraction, dynamic contrast enhancement, morphological filters | — | • | • | • | • |
Reporting | |||||
Data export to an Evident workbook | • | • | • | • | • |
Data export to Microsoft Excel | — | • | • | • | • |
Report and presentation creation in Microsoft 365, Office 2019, and Office 2021 | — | ◦ | • | • | • |
Device Support*1 | |||||
Evident microscopes*2 and Evident cameras*3 | • | • | • | — | — |
Third-party X,Y motorized stages (LUDL, PRIOR, MAERZHAEUSER, CHUOSEIKI) | — | ◦ | ◦ | — | — |
Third-party X,Y motorized focus drive (LUDL, PRIOR, MAERZHAEUSER, CHUOSEIKI) | — | ◦ | ◦ | — | — |
Third-party SWIR camera | — | ◦ | ◦ | — | — |
DSX1000 system and console | — | — | — | • | — |
Optional Add-Ons | |||||
Motorization | — | ◦ | ◦ | • | — |
3D Acquisition | — | ◦ | ◦ | • | — |
Count and Measure | — | ◦ | ◦ | ◦ | ◦ |
Grain Sizing | — | ◦ | ◦ | ◦ | ◦ |
Non-Metallic Inclusions | — | ◦ | ◦ | ◦ | ◦ |
Cast Iron | — | ◦ | ◦ | ◦ | ◦ |
Layer Thickness | — | ◦ | ◦ | ◦ | ◦ |
Porosity | — | ◦ | ◦ | ◦ | ◦ |
Particle Distribution | — | ◦ | ◦ | ◦ | ◦ |
Coating Thickness | — | ◦ | ◦ | ◦ | ◦ |
Phase Analysis | — | ◦ | ◦ | ◦ | ◦ |
Neural Network Training | — | ◦ | ◦ | ◦ | ◦ |
Dendrite Arm Spacing | — | ◦ | ◦ | ◦ | ◦ |
Chart comparison on select standards for grain size, graphite sizing, non-metallic inclusions, and hardened metals | — | ◦ | ◦ | ◦ | ◦ |
Customized software solutions | — | ◦ | ◦ | ◦ | ◦ |
1 Please contact Evident for supported device information.
|
PC Requirements for PRECiV Capture/Core/Pro/Desktop v2.1 |
CPU | Intel® Core i5, Intel® Core i7, Intel® Xeon |
---|---|
HDD |
10 GB hard disk space for installation
Min. 50 GB for saving images and data |
RAM |
16 GB RAM (2 x 8 GB RAM)
Special requirements to the memory for certain functionality: Training of neural networks: 32 GB RAM 3D Analysis Application: 32 GB RAM |
Operating System | Windows 10 (64-bit), Windows 11 (64-bit); Editions: Pro, Pro for Workstations, Enterprise |
.Net Framework | Version 4.6.2 or higher |
Optimized resolution | 1920 × 1080 |
License activation | Using an Internet connection or code-based |
One-time migration from OLYMPUS Stream | Migration from former OLYMPUS Stream original licenses to selected PRECiV license |
Graphics card |
64 bit Graphics board with 2GB RAM
Special requirements to the graphics board for certain functionality |
PC Requirements for PRECiV DSX v2.1 |
CPU | Intel® Core i5, Intel® Core i7, Intel® Xeon |
---|---|
HDD |
10 GB hard disk space for installation
Min. 50 GB for saving images and data |
RAM |
32 GB RAM (2 x 16 GB RAM)
Special requirements to the memory for certain functionality: Training of neural networks: 32 GB RAM 3D Analysis Application: 32 GB RAM |
Operating System | Windows 10 (64-bit), Windows 11 (64-bit); Editions: Pro, Pro for Workstations, Enterprise |
.Net Framework | Version 4.6.2 or higher |
Optimized resolution | 1920 × 1080 |
License activation | Using an Internet connection or code-based |
One-time migration from OLYMPUS Stream | Migration from DSX-BSW-V1 and DSX-BSW-V2 to PRECiV DSX |
Graphics card |
64 bit Graphics board equivalent to NVIDIA Quadro P620 / T600 / T400 with 4GB RAM
Special requirements to the graphics board for certain functionality: Training of neural networks: NVIDIA graphics board compatible with CUDA 11, 6GB RAM |
应用技术
简单易用的成像、测量软件
工业实验室通常会提出苛刻的条件,而且会要求其标准操作程序获得可重复和可再现的结果。PRECiV软件通过简单而可靠的工作流程促进了检测、测量和分析。该软件为各种材料科学分析提供了多种工具,可使您对结果充满信心。
强大的成像工具
该软件支持:
- 明场
- 暗场
- MIX(定向暗场)
- 偏光
- 微分干涉(DIC)
强大的色彩渲染和分辨率提供了工业应用所需的高质量图像。PRECiV软件还提供一些可优化您的实时图像的方便的工具,包括
- 实时高动态范围(HDR)
- 防眩光
- 数字标线
- 辅助对焦
明场 | 暗场 | MIX:明场 + 暗场 |
传统:明场将光线直接照射在样品上,而传统的暗场通过从物镜侧面照亮样品来突出平面上的划痕和缺陷 | 高级:MIX是由环形LED灯产生的明场和定向暗场的组合;可以调节LED灯,以选择从哪个方向照明 |
获取全景和EFI组合图像
景深扩展成像(EFI)功能可使您通过手动和电动装置在不同焦平面上连续采集多个图像,从而获得完全对焦的图像。在手动模式下,全景功能可使您通过以手动或电动方式在整个样品上移动载物台的方法,获得大于显微镜视场的图像。
使用PRECiV软件,您现在可以在双手不离开工业显微镜的情况下将即时EFI和全景图功能组合在一起(甚至在使用手动显微镜载物台时)。彩色帧指示器表明拼接在一起的每个图像的质量,而分屏可以并排显示实时图像和拼接图像。有了电动装置,采集就可以全自动方式完成。
可轻松访问即时全景模式,以手动方式采集全景图像
EFI可使您以手动或自动方式快速采集全焦点图像
组合使用全景和EFI功能,以获得大幅全焦点图像
通过红外(IR)成像显示更多信息
红外成像模式对于质量控制和研发实验室非常重要,可以透过封装产品的硅层进行无损检测。PRECiV软件专用于单色相机的阴影校正模式可快速简便地进行IR成像。
定制的XYZ电动载物台解决方案
PRECiV软件的功能可以通过一长串定制解决方案得到扩展。以下功能用于X、Y、Z轴电动载物台。
宏观到微观
从概览图像中探测到结构,然后将颗粒轮廓转换为扫描区域,以便在更高的放大倍率下进行采集并完成进一步处理。
在晶圆上导航
读取电动或编码载物台的坐标,以设置单次长度测量的起点和终点。二维测量结果包括 X、Y、Z位置。
使用载物台进行测量
在晶圆上定义感兴趣的点,并导航到各个点以执行图像采集或处理等任务。使用三点对齐法重新定位样品,并使用带有芯片的晶圆上的行和列标记进行导航。
可重复的二维测量
PRECiV软件凭借其简单的用户界面和强大的功能,可以在实时或记录的图像上进行准确、可重复的二维测量,这些功能包括:
- 自动边缘检测*:可靠地测量点到点的距离
- 边缘检测圆*:自动探测圆的轮廓和中心
- 魔杖:自动区域检测
- 辅助线*:轻松进行复杂的几何测量
- 链接对象:链接对象以使用现有测量对象作为参照
测量结果可编入工作簿中,并导出到Excel。
*在PRECiV Pro和PRECiV Desktop中可用;在PRECiV Core中为可选配置
合规测量的引导式工作流程
PRECiV软件的引导式工作流程简化了材料科学分析。这些分步指导使结果具有可重复性和可靠性。一系列可选的材料解决方案可以添加专门的工作流程,用于材料鉴定和评估。这些解决方案可使您根据通用的国际标准(ISO、ASTM、JIS和DIN)进行分析,以在制造过程前后检查材料的质量。
精选材料解决方案(孔隙率、物相分析和粒度分布)随着人工智能(AI)技术的纳入而变得更加强大。
使用人工智能(AI)技术轻松分析复杂图像
采用TruAI技术的PRECiV软件提供了超越经典算法的图像分析。您可以将经过训练的神经网络应用于您的样品,以获得更高的重现性,进行更稳健的分析。您可在语义或实例分割方法之间进行选择,以改进神经网络训练,从而只需一步就能处理困难的应用。
可提高效率的连通性能
PRECiV软件将您的系统变成一个联通的工作站,其优点如下:
- 轻松地将图像和配置文件保存到云或网络驱动器上
- 接收自动软件更新和安全补丁
- 使用由浮动许可证服务器分配的浮动许可证
- 升级到新的软件版本
- 在工作站之间共享方法和配置文件,如测量、图像处理设置和材料解决方案设置等
您可以多种格式保存和加载图像,也可以保存包含追溯用校准信息的JPEG图像。出于安全考虑,我们可以提供重点说明NIST网络安全框架的《制造商针对医疗器械安全的披露声明》(MDS²)。
软件包
PRECiV软件可以扩展 — 您公司的不同部门可以购买所需软件级别的许可证。
PRECiV Capture
PRECiV Capture是我们的入门级软件包,适用于希望使用现有工业显微镜获取数字图像和进行基本二维测量的客户,如对来料进行检测。
PRECiV Core
PRECiV Core非常适合于在QA实验室和检验室工作、重点关注图像的客户,这款软件成本不高、功能不少,添加的景深扩展成像和测量值导出功能使其物超所值。
PRECiV PRO
PRECiV Pro功能齐全,是目前为止该软件最强大、用途最广泛的版本。PRECiV Pro版本为QA/QC和故障分析部门的客户以及任何需要生成分析报告和测量值以验证样品或生产批次的人员提供了所需的工具。
PRECiV Desktop
PRECiV Desktop版本专为希望使用所有可用的测量和分析功能,在远离工业显微镜的地方进行数据后期处理的客户而打造,不提供相机和图像采集控件。
Capture | Core | Pro | Desktop | |
图像采集 | ||||
使用奥林巴斯相机进行基本图像采集,包括自动校准 | Y | Y | Y | X |
扩展的图像采集功能,包括HDR、实时HDR(使用DP74相机)和位置导航器 | Y | Y | Y | X |
使用MIX滑块(工业显微镜)或LED环形灯(体视显微镜)去除光晕 | X | Y | Y | X |
使用手动或即时模式的景深扩展图像(EFI) | X | Y | Y | X |
使用手动或即时模式的大尺寸图像采集(全景图) | X | O | Y | X |
使用手动模式的EFI和全景组合图像 | X | O | Y | X |
图像和自定义工具 | ||||
按用途分组功能的用户界面 | Y | Y | Y | Y |
叠加信息层(比例尺、十字线、数字标线) | Y | Y | Y | X |
静态注解 | Y | Y | Y | Y |
实时缩放 | Y | Y | Y | X |
测量/图像分析 | ||||
基本交互式测量(任意线、圆到圆的距离、折线、自由折线、线性尺、垂线、自由多边形、矩形、旋转矩形、3点圆、3点夹角、4点夹角、点坐标、点计数) | Y | Y | Y | Y |
高级交互式测量,包括自动边缘检测和辅助线(水平线、垂直线、角度尺、2点圆、旋转椭圆、闭合多边形、魔杖、插值多边形、多条垂直线、不对称线、焊缝厚度) | X | O | Y | Y |
图像增强过滤器(边缘检测过滤器、平滑过滤器和锐化过滤器)、强度和对比度调整、阴影校正和背景减法、动态对比度增强、形态过滤器 | X | Y | Y | Y |
报告 | ||||
数据导出到奥林巴斯工作簿 | Y | Y | Y | Y |
数据导出到Microsoft Excel | X | Y | Y | Y |
在Microsoft 365或Office 2019、2021中创建报告和演示文稿 | X | O | Y | Y |
设备支持*1 | ||||
Evident工业显微镜*2和Evident相机*3 | Y | Y | Y | X |
第三方SWIR相机 | X | O | O | X |
支持载物台、控制器和聚焦驱动器*4 | X | O | O | X |
可选附加件 | ||||
计数和测量 | X | O | O | O |
PRECiV的材料解决方案(如晶粒度、非金属夹杂物、铸铁、层厚、孔隙率、颗粒分布、涂层厚度、相分析、枝晶臂间距) | X | O | O | O |
关于晶粒度、石墨粒度、非金属夹杂物和硬化金属的选定标准的图表比较 | X | O | O | O |
机动化(X、Y、Z)— 包括延时和视频录制 | X | O | O | X |
采集三维图像(仅限Z控制) | X | O | O | X |
TruAI深度学习(神经网络训练) | X | O | O | O |
定制软件解决方案 | X | O | O | O |
PRECiV — OLYMPUS Stream迁移 | ||||
自OLYMPUS Stream Start的一次性迁移*5 | O | X | X | X |
自OLYMPUS Stream Basic的一次性迁移*5 | X | O | X | X |
自OLYMPUS Stream Essentials / Motion的一次性迁移*5 | X | X | O | X |
自OLYMPUS Stream Desktop的一次性迁移*5 | X | X | X | O |
Y为标准功能;O为可选功能;X是不可用 |
对PC机的要求 | |
CPU | Intel Core i5、i7;Intel Xeon、同等配置或更高的配置 |
RAM/HDD | 16 GB/2.4 GB可用空间 |
操作系统 | Windows 10(64位)和Windows 11(64位)- 专业版(Pro)、工作站专业版(Pro for Workstation)、企业版(Enterprise) |
.Net Framework | 4.6.2或更高版本 |
优化的分辨率 | 1920 × 1080 |
许可证类型 | 联网或密码 |
显卡 | 具有2 GB RAM的64位显卡(特殊组合可与CUDA 9.1兼容),某些功能(LiveHDR、AI神经网络训练和应用)对显卡有额外要求。 |
如需完整列表,请参阅我们定期更新的硬件要求列表。
1 请联系Evident获取受支持设备的信息
2 支持BX41M-LED、BX51、BX51M、BX53M、GX41、GX51、GX53、GX71、MX51、MX63、MX63L、SZ61、SZX7、SZX9、SZX10、SZX12、SZX16、BX3M-CB、BX3M-CBFM、BXFM。
3 支持LC30、LC35、DP22、DP23、DP23M DP27、DP28、DP73、DP73 WDR、DP74、SC30、SC50、SC100、SC180、UC90。
4 支持Chuoseiki:QT-ADM3、MSS-50C-OB、MSS-50WC-OB、MSS-150C、MSS-399C、MSSS-FM1;ludl:MAC6000、96S100、96S109-LE、96S103-6-LE、96S106-O3-LE、96A404;Märzhäuser:TANGO、SCAN 75x50、SCAN130x85、SCAN 225x76、SCAN 200x200、SCAN 300x300、MFD-2;Prior:ProScan 3、ES111、H101F、H105、H112、H117、PS3H122R;物镜成像:OASIS(虽然连接已验证,但不保证操作。)
5 从Olympus Stream 2.2、2.3、2.4和2.5原始许可证迁移到所选的PRECiV许可证。
资源库
视频产品信息说明册 |
